Description
Key Feature of Leica Flexline TS 03 Reflectorless Total Station
Leica FlexLine TS03 is a classic manual total station for standard measuring tasks, enabling you to carry out most survey and layout tasks easily and efficiently.
Be it building construction, civil engineering or surveying and mapping – the Leica TS03 helps you tackle your daily challenges and tasks trouble-free:
- Managing directors of construction departments benefit from minimal downtime of your survey crews to deliver projects under budget and in time.
- Survey managers can rely on the highest product durability in the market, which increases your planning certainty.
- Surveyors work faster by measuring more points per day with less measurement errors and rework.
Leica FlexLine: The new generation of manual total stations
- results.
Leica FlexField software: Comprehensive, intuitive and easy to use
- The Flexline TS03 Total Station is equipped with the Leica FlexField software, an intuitive, easy-to-use and familiar software. Guided workflows and easy to understand graphics and icons ensure a low learning curve when working in the field. The software makes the interpretation of measurement values or text no longer necessary and guarantees a faster and simple operation when you need it. With its pinpoint distance measurement system, you will be able to measure to both prisms and any surfaces.
- The Leica FlexLine TS03 Reflectorless Manual Total Station is one of the top-class instruments with an accurate EDM (Electronic Distance Measurement) technology that offers a reflectorless range up to 1,640 feet (500 m). This manual total station operates a range of 11,483 feet (3,500 m) using a single prism. It is also equipped with a broad application-based Leica FlexField software for better surveying and stakeout performance.
- The FlexLine TS 03 total station features a quadruple axis compensation that has a setting accuracy of up to 0.5 second and range of ±4’. For better target viewing, the TS03 telescope has a 30x magnification, 3″ resolving power and a focusing range of 5.05 feet to infinity. It utilizes a Laserclass 2 laser plummet that covers a diameter of 0.1 inches at 4.9 feet instrument height. To easily manage data, it has an RS232 interface and a USB stick/SD card interface, which can accommodate 2GB internal flash memory and a 1GB SD card RAM.
Leica Total Station Flexline TS03 Technical Specifications:
Leica FlexLine TS03 ( ANGULAR MEASUREMENT )
| Accuracy Hz and V | Absolute, continuous, diametrical | 2″ / 3″ / 5″ |
|
yes |
DISTANCE MEASUREMENT
| Range |
|
yes |
| Non-Prism / Any surface | ||
| R500 | yes | |
| R1000 | no | |
| Accuracy / Measurement time | Single prism
|
yes |
Non-Prism / Any surface
|
yes | |
| Laser dot size |
|
yes |
| Telescope |
|
yes |
GENERAL
| Display and keyboard | 3.5“ (inch), 320 x 240 px QVGA, grayscale, 28 keys | yes |
| 2nd keyboard | no | |
| Key illumination | no | |
| Operation |
|
yes |
| Power management | Exchangeable Lithium-Ion battery | yes |
| Operating time with GEB361 | up to 30h | |
| Operating time with GEB331 | up to 15h | |
| Battery charging time with | ||
| GKL341 charger for GEB361 / GEB331 | 3h 30min / 3h | |
| GKL311 charger for GEB361 / GEB331 | 6h 30min / 3h 30min | |
| Data storage |
|
yes |
| Processor |
|
yes |
| Interfaces | RS2327, USB device | yes |
| Bluetooth®8, WLAN9 | no | |
| Mobile Data sidecover: LTE-Modem for internet access | no | |
| Guide Light (EGL) |
|
no |
| Laser plummet (Laserclass 2) |
Accuracy
|
yes |
| AutoHeight module for automatic instrument height measurement (Laserclass 2) | Accuracy
|
no |
| Weight | 4.3kg | |
| Environmental specifications | Working temperature range: –20°C to +50°C | yes |
| Arctic version: –35°C to +50°C | no | |
| Dust / Water (IEC 60529) / Humidity: IP66 / 95%, non-condensing | yes | |
| Military Standard 810G, Method 506.5 | yes | |
